2 Introduction to the Access SDK and API

2.6.2.2.1 Annotated Code: JAccess Client.java

Import standard Java library class Hashtable to hold credentials.

import java.io.Hashtable;

Import the library containing the Java implementation of the Access SDK API classes.:

import oracle.security.am.asdk.*;

This application is named JAccessClient.

public class JAccessClient {

Since this is the simplest of example applications, we are declaring global constants to represent the parameters associated with a user request for access to a resource.

Typically, a real-world application receives this set of parameters as an array of strings passed from a requesting application, HTTP FORM-based input, or command-line input. For example:

public static final String ms_resource = "//Example.com:80/secrets/index.html";
   public static final String ms_protocol = "http";
   public static final String ms_method = "GET";
   public static final String ms_login = "jsmith";
   public static final String ms_passwd = "j5m1th";

Launch the main method on the Java interpreter. An array of strings named argv is passed to the main method. In this particular case, the user jsmith, whose password is j5m1th, has requested the HTTP resource //Example.com:80/secrets/index.html. GET is the specific HTTP operation that will be performed against the requested resource. For details about supported HTTP operations and protecting resources with application domains, see Oracle Fusion Middleware Administrator's Guide for Oracle Access Manager with Oracle Security Token Service.

public static void main(String argv[]) {

Place all relevant program statements in the main method within a large try block so that any exceptions are caught by the catch block at the end of the program.

AccessClient ac = null;

 try {

Initialize the Access SDK by creating AccessClient instance by providing directory location of configuration file ObAccessClient.xml. There are multiple ways to provide configuration location to initialize the Access SDK. For more information refer to Oracle Access Manager Access SDK Java API Reference.

You only need to create an instance of AccessClient and it initializes Access SDK API. AccessClient.CompatibilityMode.OAM_10G indicates that Access SDK will be initialized to work in a mode which is compatible with both the 10g and 11g releases of Oracle Access Manager.

ac = AccessClient.createDefaultInstance(m_configLocation ,
 AccessClient.CompatibilityMode.OAM_10G);

Create a new resource request object named rrq using the ResourceRequest constructor with the following three parameters:

• ms_protocol, which represents the type of resource being requested. When left unspecified, the default value is HTTP. EJB is another possible value, although this particular example does not cover such a case. You can also create custom types, as described in the Oracle Fusion Middleware Administrator's Guide for Oracle Access Manager with Oracle Security Token Service.

• ms_resource, which is the name of the resource. Since the requested resource type for this particular example is HTTP, it is legal to prepend a host name and port number to the resource name, as in the following:

  //Example.com:80/secrets/index.html


• ms_method, which is the type of operation to be performed against the resource. When the resource type is HTTP, the possible operations are GET and POST. For EJB-type resources, the operation must be EXECUTE. For custom resource types, you define the permitted operations when you set up the resource type. For more information on defining resource types and protecting resources with application domains, see the Oracle Fusion Middleware Administrator's Guide for Oracle Access Manager with Oracle Security Token Service.

ResourceRequest rrq = new ResourceRequest(ms_protocol,
   ms_resource, ms_method);

Determine whether the requested resource rrq is protected by an authentication scheme.

if (rrq.isProtected()) {

If the resource is protected, report that fact.

System.out.println("Resource is protected.");

Use the AuthenticationScheme constructor to create an authorization scheme object named authnScheme. Specify the resource request rrq so that AuthenticationScheme checks for the specific authorization scheme associated with that particular resource.

AuthenticationScheme authnScheme =new AuthenticationScheme(rrq);

Determine if the authorization scheme is FORM-based.

if (authnScheme.isForm()) {

If the authorization scheme does use HTTP FORM as the challenge method, report that fact, then create a hashtable named creds to hold the name:value pairs representing the user name (userid) and the user password (password). Read the values for ms_login and ms_passwd into the hashtable.

System.out.println("Form Authentication Scheme.");
Hashtable creds = new Hashtable();
creds.put("userid", ms_login);
creds.put("password", ms_passwd);

Using the UserSession constructor, create a user session object named session. Specify the resource request as rrq and the authentication scheme as creds so that UserSession can return the new structure with state information as to whether the authentication attempt has succeeded.

UserSession session = new UserSession(rrq, creds);

Invoke the getStatus method on the UserSession state information to determine if the user is now successfully logged in (authenticated).

if (session.getStatus() == UserSession.LOGGEDIN) {

If the user is authenticated, determine if the user is authorized to access the resource specified through the resource request structure rrq.

if (session.isAuthorized(rrq)) {
  System.out.println(
    "User is logged in " +
    "and authorized for the request " +

Determine the authorization level returned by the getLevel method for the user session named session.

"at level " + session.getLevel());

If the user is not authorized for the resource specified in rrq, then report that the user is authenticated but not authorized to access the requested resource.

} else {
  System.out.println("User is logged in but NOT authorized");

If the user is not authenticated, report that fact. (A real world application might give the user additional chances to authenticate).

} else {
  System.out.println("User is NOT logged in");

If the authentication scheme does not use an HTTP FORM-based challenge method, report that fact. At this point, a real-world application might branch to facilitate whatever other challenge method the authorization scheme specifies, such as basic (which requires only userid and password), certificate (SSL or TLS over HTTPS), or secure (HTTPS through a redirection URL). For more information about challenge Methods and configuring user authentication, see the Oracle Fusion Middleware Administrator's Guide for Oracle Access Manager with Oracle Security Token Service.

} else {
  System.out.println("non-Form Authentication Scheme.");
}

If the resource is not protected, report that fact. (By implication, the user gains access to the requested resource, because the Access Client makes no further attempt to protect the resource).

} else {
  System.out.println("Resource is NOT protected.");
}
}

If an error occurs anywhere within the preceding try block, get the associated text message from object ae and report it.

catch (AccessException ae) {
  System.out.println(
  "Access Exception: " + ae.getMessage());
}

If the application need to logout user, then it can invoke logoff method on the object of UserSession class.

Now that the program is finished calling the OAM Server, shut down the API, thus releasing any memory the API might have maintained between calls.

ac.shutdown();
}
}

Exit the program. You don't have to deallocate the memory used by the structures created by this application because Java Garbage Collection automatically cleans up unused structures when it determines that they are no longer needed.

2.6.2.3.1 Annotated Code: Java Login Servlet

Import standard Java packages to support input and output and basic functionality.

import java.io.*;
import java.util.*;

Import two packages of Java extensions to provide servlet-related functionality.

import javax.servlet.*;
import javax.servlet.http.*;

Import the package oracle.security.am.asdk.jar, which is the Java implementation of the Access SDK API.

import oracle.security.am.asdk.*;

This servlet, which builds on the functionality of the generic HttpServlet supported by the Java Enterprise Edition, is named LoginServlet.

public class LoginServlet extends HttpServlet {

The init method is called once by the servlet engine to initialize the Access Client. In init method, Access SDK can be initialized by instantiating AccessClient by passing the location of the configuration file ObAccessClient.xml file. For more information for creating Access Client refer to Oracle Access Manager Access SDK Java API Reference. OAM_10g compatibility flag initialized Access SDK in a mode such that it is compatible with both OAM 10g server and OAM 11g server.

In the case of initialization failure, report that fact, along with the appropriate error message.

public void init() {
      AccessClient ac =
 AccessClient.createDefaultInstance("/myfolder" ,
 AccessClient.CompatibilityMode.OAM_10G);
   } catch (AccessException ae) {
         ae.printStackTrace();
   }
}

Invoke the javax.servlet.service method to process the user's resource request.

public void service(HttpServletRequest request, HttpServletResponse response)
  throws IOException, ServletException {

Initialize members as null. These will store the Access structures used to process the resource request, then set the response type used by this application to text/html.

AuthenticationScheme authnScheme = null;
UserSession user = null;
ResourceRequest resource = null;
response.setContentType("text/html");

Open an output stream titled LoginServlet: Error Page and direct it to the user's browser.

PrintWriter out = response.getWriter();
out.println("<HTML>");
out.println("<HEAD><TITLE>LoginServlet: Error Page</TITLE></HEAD>");
out.println("<BODY>");

Determine if a session already exists for this user. Invoke the getSession method with false as a parameter, so the value of the existing servlet session (and not the UserSession) will be returned if it is present; otherwise, NULL will be returned.

HttpSession session = request.getSession(false);

Retrieve the name of the target resource, assign it to the variable requestedPage, then retrieve the name of the HTTP method (such as GET, POST, or PUT) with which the request was made and assign it to the variable reqMethod.

String requestedPage = request.getParameter(Constants.REQUEST);
String reqMethod = request.getMethod();

Create a hashtable named cred to hold the user's credentials.

Hashtable cred = new Hashtable();

If the variable requestedPage is returned empty, report that the name of the target resource has not been properly specified, then terminate the servlet.

try {
   if (requestedPage == null) {
out.println("<p>REQUESTED PAGE NOT SPECIFIED\n");
out.println("</BODY></HTML>");
return;
   }

If the name of the requested page is returned, create a ResourceRequest structure and set the following:

• The resource type is HTTP

• The HTTP method is GET

• resource is the value stored by the variable requestedPage

resource = new ResourceRequest("http", requestedPage, "GET");

If the target resource is protected, create an AuthenticationScheme structure for the resource request and name it authnScheme.

if (resource.isProtected()) {
   authnScheme = new AuthenticationScheme(resource);

If the authentication scheme associated with the target resource is HTTP basic and no user session currently exists, invoke javax.servlet.servletrequest. getParameter to return the user's credentials (user name and password) and assign them to the variables sUserName and sPassword, respectively.

For the authnScheme.isBasic call in the following statement to work properly, the user name and password must be included in the query string of the user's HTTP request, as in the following:

http://host.example.com/resource?username=bob&userpassword=bobspassword

where resource is the resource being requested, bob is the user making the request, and bobspassword is the user's password.

Additional Code for authnScheme.isForm

1. Process the original request and determine that form-based login is required.

2. Send a 302 redirect response for the login form and also save the original resource information in the HTTP session.

3. Authenticate the user by processing the posted form data with the user's name and password.

4. Retrieve the original resource from the HTTP resource and sends a 302 redirect response for the original resource.

5. Process the original request once again, this time using the UserSession stored in the HTTP session.

if (authnScheme.isBasic()) {
   if (session == null) {
      String sUserName = request.getParameter(Constants.USERNAME);
      String sPassword = request.getParameter(Constants.PASSWORD);

If the user name exists, read it, along with the associated password, into the hashtable named cred.

if (sUserName != null) {
   cred.put("userid", sUserName);
   cred.put("password", sPassword);

Create a user session based on the information in the ResourceRequest structure named resource and the hashtable cred.

user = new UserSession(resource, cred);

If the status code for the user returns as LOGGEDIN, that user has authenticated successfully.

if (user.getStatus() == UserSession.LOGGEDIN) {

Determine if the user is authorized to access the target resource.

if (user.isAuthorized(resource)) {

Create a servlet user session (which is not to be confused with an UserSession) and add the name of the user to it.

session = request.getSession( true);
session.putValue( "user", user);

Redirect the user's browser to the target page.

response.sendRedirect(requestedPage);

If the user is not authorized to access the target resource, report that fact.

} else {
    out.println("<p>User " + sUserName + " not authorized
      for " + requestedPage + "\n");
 }

If the user is not properly authenticated, report that fact.

} else {
    out.println("<p>User" + sUserName + "NOT LOGGED IN\n");
}

If the user name has not been supplied, report that fact.

} else {
out.println("<p>USERNAME PARAM REQUIRED\n");
}

If a session already exists, retrieve USER and assign it to the session variable user.

} else {
    user = (UserSession)session.getValue("user");

If the user is logged in, which is to say, the user has authenticated successfully, report that fact along with the user's name.

if (user.getStatus() == UserSession.LOGGEDIN) {
      out.println("<p>User " + user.getUserIdentity() + " already
      LOGGEDIN\n");
 }
}

If the target resource is not protected by a basic authentication scheme, report that fact.

} else {
   out.println("<p>Resource Page" + requestedPage + " is not protected
         with BASIC\n");
}

If the target resource is not protected by any authentication scheme, report that fact.

} else {
   out.println("<p>Page " + requestedPage + " is not protected\n");
}

If an error occurs, report the backtrace.

} catch (AccessException ex) {
   oe.println(ex);
}

Complete the output stream to the user's browser.

out.println("</BODY></HTML>");
  }
}

2.6.2.4.1 Annotated Code: access_test_java.java

Import standard Java libraries to provide basic utilities, enumeration, and token processing capabilities.

import java.util.*;

Import the Access SDK API libraries.

import oracle.security.am.asdk.*;

This class is named access_test_java.

public class access_test_java {

Declare seven variable strings to store the values passed through the array named arg.

public static void main(String[] arg) {
   String userid, password, method, url, configDir, type, location;

Set the current ResourceRequest to res.

ResourceRequest res;

Initialize the hashtable parameters to null, just in case they were not already empty.

Hashtable parameters = null;

Create a new hashtable named cred.

Hashtable cred = new Hashtable();

Initialize AccessClient reference to null.

AccessClient ac = null;

If the array named arg contains less than five strings, report the expected syntax and content for command-line input, which is five mandatory arguments in the specified order, as well as the optional variables configDir, authz-parameters, and location.

if (arg.length < 5) {
  System.out.println("Usage: EXPECTED: userid password type
    HTTP-method URL [configDir [authz-parameters] [location]]]");

Since fewer than five arguments were received the first time around, break out of the main method, effectively terminating program execution.

return;
} else {

If the array named arg contains five or more strings, assign the first five arguments (arg[0] through arg[4]) to the variables userid, password, type, method, and url, respectively.

userid = arg[0];
  password = arg[1];
  type = arg[2];
  method = arg[3];
  url = arg[4];
}

If arg contains six or more arguments, assign the sixth string in the array to the variable configDir.

if (arg.length >= 6)
  configDir = arg[5];

If arg does not contain six or more arguments (in other words, we know it contains exactly five arguments, because we have already determined it does not contain fewer than five) then set configDir to NULL.

else
  configDir = null;

If arg contains at least seven strings, and arg[6] (which has been implicitly assigned to the variable authz-parameters) is not empty, create a new hashtable named parameters. The syntax for the string authz-parameters is: p1=v1&p2=v2&...

if (arg.length >= 7 && arg[6] != null) {
  parameters = new Hashtable();

Create a string tokenizer named tok1 and parse arg[6], using the ampersand character (&) as the delimiter. This breaks arg[6] into an array of tokens in the form pn=vn, where n is the sequential number of the token.

StringTokenizer tok1 = new StringTokenizer(arg[6], "&");

For all the items in tok1, return the next token as the variable nameValue. In this manner, nameValue is assigned the string pn=vn, where n is the sequential number of the token.

while (tok1.hasMoreTokens()) {
  String nameValue = tok1.nextToken();

Create a string tokenizer named tok2 and parse nameValue using the equal character (=) as the delimiter. In this manner, pn=vn breaks down into the tokens pn and vn.

StringTokenizer tok2 = new StringTokenizer(nameValue, "=");

Assign the first token to the variable name.

String name = tok2.nextToken();

Assign the second token to value. If additional tokens remain in tok2, return the next token and assign it to value; otherwise, assign an empty string to value.

String value = tok2.hasMoreTokens() ? tok2.nextToken() : "";

Insert name and value into the hashtable parameters.

parameters.put(name, value);
  }
}

If there are eight or more arguments in arg, assign arg[7] to the variable location; otherwise make location empty.

location = arg.length >= 8 ? arg[7] : null;

Create AccessClient instance using configDir, in case if its null provide configuration file location using other options. For more information for creating Access Client, see Oracle Access Manager Access SDK Java API Reference.

try {
 ac = AccessClient.createDefaultInstance(configDir ,
   AccessClient.CompatibilityMode.OAM_10G);
}

If the initialization attempt produces an error, report the appropriate error message (ae) to the standard error stream along with the backtrace.

catch (AccessException ae) {
  System.out.println("
OAM Server SDK Initialize failed");
  ae.printStackTrace();

Break out of the main method, effectively terminating the program.

return;
}

Read the variables, user ID, and password into the hashtable named cred.

cred.put("userid", userid);
cred.put("password", password);

Create a ResourceRequest object named res, which returns values for the variables type, url and method from the OAM Server.

try {
res = new ResourceRequest(type, url, method);

Determine whether the requested resource res is protected and display the appropriate message.

if (res.isProtected())
  System.out.println("Resource " + type ":" + url + " protected");
else
  System.out.println("Resource " + type + ":" + url + " unprotected");
}

If the attempt to create the ResourceRequest structure does not succeed, report the failure along with the error message t.

catch (Throwable t) {
  t.printStackTrace();
  System.out.println("Failed to create new resource request");

Break out of the main method, effectively terminating the program.

return;
}

Set the UserSession parameter user to empty.

UserSession user = null;

Create a UserSession structure named user so that it returns values for the ResourceRequest structure res and the AuthenticationScheme structure cred.

try
  user = new UserSession(res, cred);

If the attempt to create the UserSession structure does not succeed, then report the failure along with the error message t.

catch (Throwable t) {
  t.printStackTrace();
  System.out.println("Failed to create new user session");

Break out of the main method, effectively terminating the program.

return;
}

Determine if the user is currently logged in, which is to say, authentication for this user has succeeded.

try
{
if (user.getStatus() == UserSession.LOGGEDIN) {

If the user is logged in, determine whether the variable location is not empty. If location is not empty, set the location parameter for AccessClient to the value of the variable location, then report that the user is logged in along with the status code returned by the OAM Server.

if (location != null) user.setLocation(location);
System.out.println("user status is " + user.getStatus());

Check authorization. To accomplish this, determine whether parameters exists. If it does, determine whether the user is authorized with respect to the target resource when the parameters stored in parameters are attached. If parameters does not exist, simply determine whether the user is authorized for the target resource.

try {
  if (parameters != null ? user.isAuthorized(res, parameters) :
    user.isAuthorized(res)) {

If the user is authorized to access the resource when all the appropriate parameters have been specified, report that permission has been granted.

System.out.println("Permission GRANTED");

Display also a serialized representation of the user session token.

System.out.println("User Session Token =" + user.getSessionToken());

If the variable location is not empty, report the location.

if (location != null) {
  System.out.println("Location = " + user.getLocation());
}

If the user is not authorized to access the resource, report that permission has been denied.

} else {
System.out.println("Permission DENIED");

If UserSession returns ERR_NEED_MORE_DATA, set the variable nParams to the number of parameters required for authorization, then report that number to the user.

if (user.getError() == UserSession.ERR_NEED_MORE_DATA) {
  int nParams = res.getNumberOfAuthorizationParameters();
  System.out.print("Required Authorization Parameters (" +
    nParams + ") :");

Set e to the value of the keys parameter in the hashtable returned by the getAuthorizationParameters method for the ResourceRequest object named "res."

Enumeration e = res.getAuthorizationParameters().keys();

Report the names of all the elements contained in e.

while (e.hasMoreElements()) {
  String name = (String) e.nextElement();
  System.out.print(" " + name);
}
System.out.println();
}

Otherwise, simply proceed to the next statement.

else
  }
}

If the user is not logged in, report the current user status.

else
  System.out.println("user status is " + user.getStatus());

In the case of an error, report that the authorization attempt failed.

catch (AccessException ae)
  System.out.println("Failed to get user authorization");
}

Now report all the actions currently set for the current user session. Do this by creating an array named actionTypes from the strings returned by the getActionTypes method. Next, read each string in actionTypes into a hashtable named actions. Report the name and value of each of the keys contained in actions.

String[] actionTypes = user.getActionTypes();
for(int i =0; actionTypes[i] != null; i++){
  Hashtable actions = user.getActions(actionTypes[i]);
  Enumeration e = actions.keys();
  int item = 0;
  System.out.println("Printing Actions for type " + actionTypes[i]);
  while(e.hasMoreElements()) {
String name = (String)e.nextElement();
System.out.println("Actions[" + item +"]: Name " + name + " value " +
  actions.get(name));
item++;
  }
}

Attempt to create an AuthenticationScheme object named auths for the ResourceRequest object res.

AuthenticationScheme auths;
try
  auths = new AuthenticationScheme(res);

If the AuthenticationScheme creation attempt is unsuccessful, report the failure along with the error message ase.

catch (AccessException ase) {
  ase.printStackTrace();

Break out of the main method, effectively terminating the program.

return;
}

Determine if the authorization scheme is basic.

try
{
if (auths.isBasic())

If it is, report the fact.

System.out.println("Auth scheme is Basic");

It it is not basic, report the fact.

else
  System.out.println("Auth scheme is NOT Basic");

Use the copy constructor to create a new ResourceRequest object named resNEW from the original object res.

ResourceRequest resNew = (ResourceRequest) res.clone();

Report the name of the newly cloned object.

System.out.println("Clone resource Name: " + resNew.getResource());

If the ResourceRequest object cannot be cloned for any reason, report the failure along with the associated backtrace.

}
catch (Exception e) {
  e.printStackTrace();
}

Set the ResourceRequest object res and the AuthenticationScheme object auths to NULL, then disconnect the Access SDK API.

res = null;
    auths = null;
    ac.shutdown();
  }
}

2.9.3.2.1 Initializing and Uninitializing Access SDK

In Oracle Access Manager 10g JNI SDK, the com.oblix.access.ObConfig class provides a function to perform ASDK initialization and uninitialization. In Oracle Access Manager 11g Access SDK, the oracle.security.am.asdk.AccessClient provides this function.

As with Oracle Access Manager 10g JNI SDK, the Access Client application instance can work with a given configuration.

Depending on the requirement, you can use the AccessClient class in two different ways:

• You can use the createDefaultInstance static function to create a single instance of the AccessClient class. Only a single default instance of this class is permitted. Invoking this method multiple times within a single instance of the Access Client application causes an exception.

  If you use the createDefaultInstance method, you must use the AccessClient class instance obtained using this method when instantiating any of AuthenticationScheme, ResourceRequest, or UserSession classes

• You can use the createInstance static function to create a new AccessClient class instance initialized with a given configuration. This class is required when it is within the same running instance of an Access Client application, and the application must work with different Oracle Access Manager systems or different configurations. Each AccessClient class instance can log its messages to different log files by passing in an appropriate logger name while constructing the Access Client instances.

  You must pass AccessClient.CompatibilityMode.OAM_10G in compatibility mode when initializing AccessClient objects.

  If you use the createInstance method, you must use the AccessClient class instance obtained using this method when instantiating the AuthenticationScheme, ResourceRequest, or UserSession classes.

While the application is shutting down, it should invoke the AccessClient class shutdown method to perform uninitialization as shown in the following examples:

• For Oracle Access Manager 10g JNI ASDK

  Public static void main (String args[]) {
    try {
     ObConfig.Initialize (); // Configuration is read from the location pointed by OBACCESS_INSTALL_DIR
                                           // environment variable


  OR

  ObConfig.Initialize (configLocation); //Configuration is read from the location provided
     ………..
     }catch (ObAccessException e){
     }
  ObConfig.shutdown();
  }//main ends here


• For Oracle Access Manager 11g Access SDK

  import java.io.*;
  import java.util.*;
  import oracle.security.am.asdk.*; //Import classes from OAM11g Access ASDK
  …………..
  Public static void main (String args[]) {
    try {
       ac = AccessClient.createDefaultInstance (“”, AccessClient.CompatibilityMode.OAM_10G); // Refer to Oracle Access Manager Access SDK Java API Reference


  OR

  AccessClient.createInstance(“”,AccessClient.CompatibilityMode.OAM_10G); // Refer to Oracle Access Manager Access SDK Java API Reference
     ………..
     }catch (AccessException e){
     }
  ac.shutdown();
  }//main ends here


2.9.3.2.2 Performing Access Operations

As shown in Table 2-6, there is a one-to-one mapping between the classes that are used to perform access operations. The classes in oracle.security.am.asdk are AuthenticationScheme, ResourceRequest, and UserSession.

Depending how the AccessClient class is instantiated, use the corresponding constructor of these classes.

Similar to Oracle Access Manager 10g JNI ASDK, any error that occurs during initialization or while performing access operations, is reported as an exception. AccessException is the exception class used in Oracle Access Manager 11g Access SDK as seen in the following examples:

• For Oracle Access Manager 10g JNI ASDK

  Public static void main (String args[]) {
    try {
     ObConfig.Initialize (); // Configuration is read from the location pointed by OBACCESS_INSTALL_DIR
                                           // environment variable
     ObResourceRequest rrq = new ObResourceRequest(ms_protocol, ms_resource,ms_method);
     if (rrq.isProtected()) {
       System.out.println("Resource is protected.");
       ObAuthenticationScheme authnScheme = new ObAuthenticationScheme(rrq);
       if (authnScheme.isForm()) {
         System.out.println("Form Authentication Scheme.");
         Hashtable creds = new Hashtable();
         creds.put("userid", ms_login);
         creds.put("password", ms_passwd);
         ObUserSession session = new ObUserSession(rrq, creds);
         if (session.getStatus() == ObUserSession.LOGGEDIN) {
           if (session.isAuthorized(rrq)) {
             System.out.println("User is logged in and authorized for the
             request at level " + session.getLevel());
           } else {
             System.out.println("User is logged in but NOT authorized");
           }
        } else {
          System.out.println("User is NOT logged in");
       }
     } else {
       System.out.println("non-Form Authentication Scheme.");
    }
  } else {
    System.out.println("Resource is NOT protected.");
  }
  }catch (ObAccessException oe) {
    System.out.println("Access Exception: " + oe.getMessage());
  }
  ObConfig.shutdown();
  }//main ends here


• For Oracle Access Manager 11g Access SDK

  import java.io.*;
  import java.util.*;
  import oracle.security.am.asdk.*; //Import classes from OAM11g Access ASDK

  Public static void main (String args[]) {
    AccessClient ac;
    try {
      ac = AccessClient.createDefaultInstance(“”,
       AccessClient.CompatibilityMode.OAM_10G);

      ResourceRequest rrq = new ResourceRequest(ms_protocol,ms_resource, ms_method);

      if (rrq.isProtected()) {
        System.out.println("Resource is protected.");
        AuthenticationScheme authnScheme =new AuthenticationScheme(rrq);
        if (authnScheme.isForm()) {
          System.out.println("Form Authentication Scheme.");
          Hashtable creds = new Hashtable();
          creds.put("userid", ms_login);
          creds.put("password", ms_passwd);
          creds.put("ip", ms_ip);
          creds.put("operation", ms_method);
          creds.put("resource", ms_resource);
          creds.put(“targethost”, ms_targethost);

          UserSession session = new UserSession(rrq, creds);
          if (session.getStatus() == UserSession.LOGGEDIN) {
            if (session.isAuthorized(rrq)) {
              System.out.println("User is logged in " +
                  "and authorized for the request " +"at level " + session.getLevel());
            } else {
              System.out.println("User is logged in but NOT authorized");
            }
          } else {
            System.out.println("User is NOT logged in");
          }
        }
      }catch (AccessException oe) {
        System.out.println("Access Exception: " + oe.getMessage());
      }
      ac.shutdown();
  } //main ends here
