17 Managing the Persistent Event Store

This section contains the typical persistent event store management tasks you can perform with Oracle CEP Visualizer, including:

Section 17.1, "Viewing the Persistent Event Store"
Section 17.2, "Configuring the Persistent Event Store"

For more information, see Section 9.7, "Persistent Event Store Management".

17.1 Viewing the Persistent Event Store

You can view the persistent event store using the Oracle CEP Visualizer.

17.1.1 How to View the Persistent Event Store

Using the Oracle CEP Visualizer, you can view the persistent event store.

To view the persistent event store:

In the left pane, click Domain > Server > Services > Event Repository, where Domain refers to the name of your Oracle CEP domain and Server refers to the name of the server instance.

The Event Repository panel appears as Figure 17-1 shows. Table 17-1 describes the options in this panel.

Figure 17-1 Event Repository Panel

Description of "Figure 17-1 Event Repository Panel"

Table 17-1 Event Repository Panel Attributes

Attribute Description

Attribute	Description
Provider Name	The name of the persistent event store provider. Default: `default-provider`.
Initial Timeout	The data source timeout value.
Data Source Name	Displays the JDBC data source associated with the provider.

Provider Name

The name of the persistent event store provider.

Default: default-provider.

Initial Timeout

The data source timeout value.

Data Source Name

Displays the JDBC data source associated with the provider.

17.2 Configuring the Persistent Event Store

You can only view the event store configured for an Oracle CEP server using Oracle CEP Visualizer. To change the configuration, you must manually update the server's config.xml file.

For details, see "Configuring an Event Store for Oracle CEP Server" in the Oracle Complex Event Processing Developer's Guide for Eclipse.
